End of the race vertical lever sheave steel Serie VP

€8.15 Tax included

€6.85 tax excl.

VP118

Electric end of the race, 1NO+1NC contacts, steel fixed roller actuator. Made of highly impact-resistant thermoplastic resin.

Part number: VP118

Representative image for illustrative purposes, the item supplied will correspond to the specifications indicated.

2 questions about the product
Privacy
Shipments
Returns


End of the race mechanical position detector, made of thermoplastic resin very resistant to shocks. The limit switch incorporates a chamber with 2 electrical contacts, one open NO and the other closed NC. The actuation of the limit switchis by means of metallic steel roller.


Operating travel (mm)



Technical characteristics:

  • Manufacturer/Supplier: Tracon
  • Part number: VP118
  • Actuator type: Ø18" metal pulley push button
  • Contacts: 1NO + 1NC
  • Rated voltage: 230Vac
  • Rated current (In): 5A AC1 230V / 2A AC15 230V / 0.3A DC13 250V
  • Rated thermal current (Ith) : 10A
  • Rated voltage of isolation: 500Vac
  • Mechanical life: 5x106 cycles
  • Material: Thermoplastic, metal actuator head
  • Input thread: M20
  • Connection cable: 0.75 - 1.5mm2
  • Ambient operating temperature: -25ºC to +55ºC
  • Degree of protection: IP65
  • Standards: EN60947-5-1, EN60947-1


Dimensions:







Material for professional use, install in compliance with the regulations in force at the place of installation.
This component should not be used for safety or hazardous applications

Questions

Question
Hola.van a 220voltios
Answer

Buenos días,

Si, pueden ser usados a 230Vac, con el limite de la intensidad máxima, tenga usted presente que la intensidad maxima es en categoria AC1 o Ith,

Como casi todos los finales de carrera, estan pensado para maniobra, es decir, si usted tiene que actuar sobre un motor, el final de carrera actua sobre un contactor y es el contactor el que acciona el motor, No se usa el final de carrera actuando directamente sobre el motor, salvo para monotores muy pequeños.

Saludos

Jose Manuel Serrano Saez on 07/05/2018 19:09:11
Question
Disponen de algún final de carrera escamoteable (inidireccional, o algún modelo que actúe en las dos direcciones independiente y NO?
Answer

Buenos días,

No, estes finales actuan en los dos sentidos.

Juan Ramón Portas Fernández on 11/21/2017 17:58:37
