Double solenoid valve 1/8 3/2 assisted (with coils) NO - Metal Work - ADAJUSA
Double solenoid valve 1/8 3/2 assisted (with coils) NO - Metal Work - ADAJUSA

Double solenoid valve 1/8 3/2 assisted tracks 24Vca NO - Metal Work

€111.94 Tax included

€94.07 tax excl.

Instead of €116.63

PK-DA183224AO
Solenoid valve 1/8 3/2 way double output NO (normally open) assisted . With 24Vac connectors and coils


Logotipo Metal Work



Representative image for illustrative purposes, the item supplied will correspond to the specifications indicated.

This pack contains

No queries yet, leave the first!
Privacy
Shipments
Returns


Double 1/8" 3/2 way NOpneumatic assisted doublesolenoid valve. The solenoid valve is normally open, i.e. without voltage on the coil, the fluid or air will be passing through the solenoid valve , when the coil is energized the passage of fluid or air will be interrupted

With plastic connectors size 22 and coils 24 Vac 3,5 VA

The supply includes:

  • 1/8" 3/2 double solenoid valve 1/8" 3/2 assisted NO
  • 2 Coils 24 Vac 3,5VA
  • 2 T22 connectors

Technical characteristics:

  • Manufacturer Metal Work
  • Part number: Metal Work: SOV 28 SES NO Code: 7010023500
  • Type of threads: G 1/8"
  • Bistable bar: Vacuum ÷ 10
  • Minimum assistance pressure bar: 2.5
  • Working temperature °C: -10 ÷ +60
  • Nominal diameter mm: 5
  • Conductance C Nl/min - bar: 121,43
  • Critical ratio b bar/bar: 0,32
  • Flow rate at 6 bar ΔP 0.5 bar Nl/min: 400
  • Flow rate at 6 bar ΔP 1 bar Nl/min: 550
  • TRA/TRR monostable at 6 bar ms: 15/35
  • TRA/TRR bistable at 6 bar ms: 20/20
  • Voltage tolerances %: -10 ÷ +15
  • Class of isolation: F 155
  • Rated voltage: 24Vac
  • Rated power: 3,5VA


Equipment for professional use, install in compliance with the regulations in force at the place of installation.
