Three-phase motor 5.5Kw 7.5hp 230/400V 1000 rpm IE3 Flange B14

Three-phase electric motor 5.5kW (7.5cv) 230/400V 1000 rpm Flange B14. Made of cast aluminum.
Standardized three-phase electric motors for general purposes, manufactured under European IEC standard in aluminum with removable foot . Windings in enameled copper with class F insulation. The execution of the housing is closed, it has a retainer on the output shaft that gives it a degree of protection IP55. IE3 energy-efficient motors.

characteristics:

• Manufacturer/Importer: Motorseg/ALREN
• Reference: ALH132M6BB144E3
• Motor type: asynchronous squirrel cage.
• Efficiency: IE3
• Voltage: 230/400 V. III. 50/60 Hz.
• number of poles: 6.
• Revolutions: 1000 (970).
• Power: 5.5 Kw (7.5 hp).
• Intensity: 21.3/11.5 A.
• Yield: 85.6%
• Continuous service: S1.
• Degree of protection: IP55.
• Clamping type: Flange B14
• Shaft diameter: Ø38mm
• Flange diameter: 200mm
• Housing size 132 (132M).
• Flange PAM: 200/38
• Color: Blue.
• Housing material: Aluminum.
• Weight: 58 Kg.
• CE marking.

For more information, other powers or executions consult.
As in any asynchronous electric motor, the installation of a motor circuit breaker is mandatory to avoid overload damage.

Pour plus d'information, vous pouvez télécharger la fiche technique en cliquant sur l'onglet «Pièces jointes». Matériel à usage professionnel, à installer conformément à la réglementation en vigueur sur le lieu d'installation.

Engine intended to be used exclusively as a spare part for machinery and / or automatic systems.
