Pressure gauge with glycerin 0 - 250 bar 63mm rear entry stainless steel case - Metal Work

Name: Pressure gauge with glycerin 0 - 250 bar 63mm rear entry stainless steel case - Metal Work
Brand: Metal Work
SKU: 6320G4G250
Price: 12.0904 EUR
Availability: InStock

€12.09 Tax included

€10.16 tax excl.

Pressure gauge diameter 63mm with stainless steel case filled with glycerin, pressure indication between 0 and 250 bar. Pressure gauge to control the pressure of installations, systems or machines. Stainless steel case with rear connection with G 1/4" thread. The internal mechanisms are made of copper alloy. With metal dial, graduation at bar. Needle in steel.

Reference: Z336320G4G250

Logotipo Metal Work

Representative image for illustrative purposes, the item supplied will correspond to the specifications indicated .

No queries yet, leave the first!

Privacy

Shipments

Returns

Pressure manometer to control the pressure of the machine or installation to be used. Pressure gauge filled with glycerin and manufactured in AISI 304 stainless steel case and internal parts in copper alloy. Rear connection with G 1/4" thread. Graduated scale at bar.
The measuring scale is graduated between 0 and 250 bar.
This manometer is specially indicated for installations where it is subjected to vibrations or pressure pulsations, the process fluid must not be corrosive, nor have a high viscosity.

This type of pressure gauge is built according to EN837-1 and accuracy class 1.6% of full scale value. White lacquered aluminum dial with black numbers.

Technical characteristics:

Field of application: For liquid and gaseous media
Diameter: 63mm
Measuring range: 0... 250 bar
Connection: G 1/4" rear
Housing and bezel: Polished stainless steel AISI, flanged bezel
Fitting: Copper alloy 1/4" Gas (BSP)
Sensing element: Copper alloy
Transmission: Copper alloy
Dial: White lacquered aluminum, scale and black numerals
Hand: Black lacquered aluminum, with chrome-plated center
Transparent: Polycarbonate
Accuracy class: ±1.6% of full scale value
Overpressure applied to the instrument at the time of adjustment: 25% of full scale value.
Working pressure:
- Constant pressure: 3/4 parts of full scale value
- Variable pressure: 2/3 of full scale value
- Pressure in short periods: full scale
Operating temperature: Max +65ºC
Ambient temperature: +5ºC to +60ºC
Temperature drift: The variation in the accuracy of the instrument will be ±0.4% every 10ºC. (Reference temperature 20ºC ±2ºC)
Degree of protection: IP65
Buffer liquid: Glycerin USP (99.8%)
Weight: 0,192 Kg

For other models or sizes, please consult us.
To mount this pressure gauge on a panel, the mounting flange, reference XNEWBRI63G, must be ordered separately, this flange is not included in the scope of supply

Dimensiones manometro glicerina 6320 con abrazadera
Note: The mounting flange is not included in the scope of supply, it must be ordered separately.

Material for professional use, install in compliance with the regulations in force at the place of installation.
